Nordre mole

Quay 812, 813

Layover quay suitable for maritime services

Nordre Mole is part of the Port of Thyboron’s outer fortifications. The quay has recently been renovated and expanded to a width of 10.5 metres, ensuring easy access for maritime services at the quay. There is plenty of room for offshore supply vessels to layover here while they wait for the next assignment in the North Sea.

There is easy access to water, electricity and other supplies at the quay, and free Wi-Fi. Nordre Mole is an ISPS-compliant quay, so the gate is closed while there are vessels berthed.

The pier has three platforms for anglers, from which they can enjoy the view of Thyboron Canal while fishing, when no large ships are berthed.

Layover quay for offshore supply vessels

It saves fuel and is eco-friendly to lay over vessels waiting for their next North Sea assignment in the immediate area. Nordre Mole is ideal for this purpose. The vessel is safely moored at port, but can be quickly dispatched to the North Sea because it is already close by.

Nordremole 5515 Web

Layover berths on both sides

It can make sense for jack-up vessels to wait in the area for their next assignment in the North Sea. Vessels can be jacked up on the outer side of Nordre Mole, and there is access to electricity, water and other supplies from the pier.

Nordremole Ovenfra 0504 Web

Easy access to supplies

The quay is equipped with a heavy-duty 125-amp power stand for large vessels and a smaller 63-amp power stand for medium-sized vessels.

Nordremole 4039 Web

Safety equipment

Nordre Mole has yellow Sea-Safe rescue ladders with LED lighting. There are three rescue ladders installed on the outside and five on the inside of the pier.

The quay has CCTV surveillance and LED lighting.

Nordremole 4045 Web
Nordremole Drone 0454 Web
Nordremole Ovenfra 0502 Web
Nordremole 4049 Web
Nordremole Drone 0546 Web
Nordremole Drone 0468 Web
Nordremole Drone 0484 Web

Technical Data - Nordre Mole

Berth number

Berth 1
812
Berth 2
813

Navigation

Water depth, m
7,5
Port entrance corridor, m
75,8
Currents, kn
0

Quay facility specifications

Dimensions

Quay length, m
185
Quay width, m
11
Quay wall in m
2

Capacity

Bearing capacity, t per m2
1
Distributet pressure, t per m2
1
Outrigger pressure at 1X1 m plate, t
20

Type

ISPS
Quay type, Sheet pile wall
Surface type quay, asphalt
Surface thickness quay, cm
11
Capping beam type, concrete

Service

Accessible for cranes
Accessibility for maritime service

Quay equipment

Supplies

Power stations
Power stations on quay
2
Power connection point, 125 amp
Power connection point, 63 amp
Power connection point, 32 amp
Water supplies at quay
Water hydrants on quay
1
Wi-Fi, fiber connection
Bunkering from barge
Bunkering capacity l/min
70-80

Safety

Safety ladders, quantity
4 + 3
Safety ladders, type SeaSafe with LED lights
Distance between safety ladders, m
50
Safety point, quantity
3

Maritime equipment

Fender type
29-5
Fenders diametre, m
1,8
Fenders width, m
0,8
Distance between fenders, m
0,9
Bollard, quantity
14
Bollard type, bean
X-6-A-F
Bollard swl, capacity, t
30
Distance between bollard, m
14

Environment

Slopoil disposal
Waste disposal
LED lightning, numbers
Lay UP 7364 Web

Wilson Adriatic ready for its next assignment in the North Sea

Offshore 20190807 163122 Adjusted Web

Carrier Express waits at Nordre Mole

Lay Up 6471 Web

Twin layover berth in a safe harbour
